Composition and structure of precision CNC lathe
Release time:
2021-12-17
Before using a precision CNC lathe, you must first have a comprehensive understanding of its structure, working principles and operating precautions. Now, let us take a look at the composition and structure of precision CNC lathes.
1. Host: It is the main body of the precision CNC machine tool, including the machine body, column, spindle, feed mechanism and other mechanical parts. It is a mechanical part used to complete various cutting processes.
2. Auxiliary device: Refers to some supporting components necessary for precision CNC machine tools to ensure the operation of CNC machine tools, such as cooling, chip removal, lubrication, lighting, monitoring, etc., including hydraulic and pneumatic devices, chip removal devices, exchange tables, CNC turntables , CNC indexing head, etc., as well as cutting tools and monitoring and testing equipment.
3. Numerical control device: It is the core of CNC machine tool, including hardware (printed circuit board, CRT display, key box, tape reader, etc.) and corresponding software. It is used to input digital parts program, complete input information storage, data conversion, interpolation calculation, and realize various control functions.
4. Drive device: the drive part of the precision CNC machine tool actuator, including the spindle drive unit, feed unit, spindle motor and feed motor. Under the control of the numerical control device, the spindle and feed drive are realized through the electro-hydraulic servo system. When multiple feeds are connected, the processing of positioning, straight line, plane curve and space curve can be completed.
5. Programming and other auxiliary equipment can be used to program and store parts outside the machine.
